Dot Peen Marking Equipment & Scribing

MSNB Portable Marker
The light weight hand held dot peen marking machine is the most compact marker for precision marking in 9 different forces powered by a Li-ON battery for long working hours.

It can be table mounted and operated with a mobile app making it an economic machine and a favourite with the customers.



The robust MNSB comes in two sizes (MNSB-53 and MNSB-155) and is suitable for marking 'difficult to access' or harder surfaces in industrial marking.

The user-friendly machine comes with a drop resistant body complete with the white and orange brand colours and LED lighting to illuminate the marking area.

Armed with its multi user interface.



Marking areas:

MNSB-53: 50 x 30 mm

MNSB-155: 150 x 50 mm



Download Catalogue



Ask About This
IMPACT
Benchtop dot peen marking machine

The Impact dot peen engraver is a standalone metal engraving machine easy to configure and master. Take your business to the next level, whatever its size and expertise.

MARKING MACHINE FOR METAL & PLASTICS

The IMPACT dot peen engraver range, is a small engraving machine that makes it possible to perform high-quality marking on a large number of materials from, metal plate engraving (painted steel, aluminum, brass, iron, steel, raw, and anodized aluminum) to plastics (ABS, PA, PP).

DOT PEEN MARKING STATION

From single part markings to small batches the IMPACT is loved for it size and versatility.

With a 300mm in clearance and open architecture traceability on, one of the smallest parts to identification on larger heavier parts are available. No job is too big. Used by automotive, aerospace, medical, and from heavy and light industries, the Impact small engraving machine has become a favorite workstation.

READY TO GO

We took all of our experience working within industrial traceability and created the IMPACT to respond to your specific needs, when both the marking requirements and the parts to be marked are constantly changing.

The IMPACT was created to be the all in one, ready to go solution, with usability at the forefront and designed to be opened and ready to start marking immediately

• TOUCH & MARK

The large color touchscreen and onboard control software make training a thing of the past. The intuitive system allows you to start marking text, logos and 2D codes straight away. Also metal plate engraving makes it the best engraving machine for metal. It makes the operator's life easy and does not require a computer.

• I-SENSE DOT PEEN MARKING STATION

The I-Sense function (Impact eZ m) detects the surface of the workpiece, automatically adjusts the height of the Z-axis and starts marking with no intervention on the part of the operator. Several adjustment modes are available: automatic mode (I-Sense), programmable mode and normal mode, which allows manual adjustment.

• DYNAMIC DOT CONTROL

Obtain a perfect result every time with the IMPACT DDC™ (Dynamic Dot Control, on Impact m and eZm) feature, a technology which enables automatic adjustment of point density according to the required size and depth of marking.

Download Catalogue



Ask About This
XF510p (Pneumatic)
The smallest and fastest on the marking all while meeting the high standards of precision.

• COMPACT DOT PEEN MARKER

With 3 sizes available our compact size is the smallest identification marking on the market. This makes the XF150p ideal for restricted spaces and whether on the line or on a robotic arm. The integration is simple in any position, reducing the time and cost of installation.

3 models available (L x w x h)

Cp: 136.4 x 87 x 137 mm (5.4 x 3.4 x 5.4 in)

Sp: 219 x 237 x 170 mm (8.6 x 9.3 x 6.7 in)

Dp: 319 x 237 x 170 mm (12.6 x 9.3 x 6.7 in)

• FAST DOT PEEN MARKING

When short cycle times are a must, the XF510p dot peen marker is for you, with a marking speed of 12 characters in one second possible, it is setting new standards for speed.

• TIRELESS PARTS MARKING

Able to work on uninterrupted production lines, the XF510p was designed to last. Made with high quality parts we have thousands of units used for aluminum plate engraving, steel engraving, and steel plate engraving worldwide, providing maximum reliability and minimum maintenance costs.

• 3D STYLUS FOR PARTS MARKING

The 3D stylus makes parts marking complex geometries easy, by adapting to the shape of each part.

The tip of the stylus extends or retracts automatically to follow the surface being marked, permitting parts marking with unequal heights, inclined planes, or abnormal surfaces with no adjustment to the Z-axis. Eliminates the need for a rotary axis on cylindrical parts.

• FAST STEEL ENGRAVING MACHINE

Be it 2D codes, dates, counters, variables, texts, serial numbers, shapes, logos, batch numbers, or just identification marking for aluminum plate engraving, steel engraving, or steel plate engraving, up to 12 characters per second, the XF510p takes fast marking to the next level for all materials up to 62HRC. With such a short cycle time the XF510p will not disappoint.

• THE INDUSTRY'S CHOICE FOR DIRECT PART MARKING

With over 50,000 units sold around world and over 15 trillion marked characters the XF510p has become the industry's go to choice for high-volume, high-speed direct part marking.

Designed for continuous use with minimum servicing time the industry relies on the XF510p for fast and accurate marking and as a fantastic return on investment.





Download Catalogue

Ask About This
XF530p (Pneumatic)
This is the perfect solution to identify parts that will withstand harsh conditions, direct marking before part processing and for anti-counterfeiting markings.

• DEEP MARKING

With up to 0.5 mm depth, the XF530 dot peen machine is the only deep engraving solution able to reach this level of depth in such a short cycle time. The marking results are clear and resistant to weather conditions, contaminants, rust, and guaranteed long-term readability. Its also the best solution to perform a direct marking before part processing, painting, or surface treatment.

• DEDICATED SOLUTION FOR LARGE CHARACTERS

The XF530 large marking area of 200 X 50 mm (8 x 2 in) is specially adapted to engrave large characters (more than 10mm (0.4 in) height) for easy readability from a long distance or in outdoor locations. This deep dot peen marking machine is the perfect solution for the oil & gas market and building industries.

• ROBUST & DURABLE This deep dot peen engraving machine in pneumatic or electromagnetic version is made of high quality and high-performance components. Its proven design has been improved for decades to obtain exceptional durability and reliability, especially in the most demanding applications. XF530 is guaranteed to have durable tamper-proof marks on all materials with a reduced cost of ownership.

• PNEUMATIC VERSION FOR SPEED

Our pneumatic dot peen machines are the best to mark text at a very short cycle time. Compressed air offers exceptional performance for markings. The stylus pin vibrates at high frequency, meeting the highest speed requirements in industrial sectors. Pneumatic dot peen is also the preferred solution to create direct marking before part processing, painting of surface treatments. The width of the line is large enough to remain legible even after a wide layer has been applied.

• MOBILE SOLUTION (Optional)

Our range of products is easily transformable into a mobile solution to mark large parts and parts that cannot be dismantled, on fixed stations or scrolling vehicle lines: a pair of large handles for easy positioning. With a standard or customizable foot, the machine is always firmly positioned on the part. 2 rings at the top that can be connected as a balancer making easy operator work, suppress troubles related to heavy handling and to integrate into pipeline marking.

Download Catalogue

Ask About This
XF510m (Electromagnetic)
The master of marking Datamatrix codes, this electromagnetic dot peen engraver builds upon our foundations with dot peen to meet the highest standards of precision.

• HIGH-PERFORMANCE

With automatic density adjustment to maximize marking speed, readability, automatic part detection and multi-level marking the XF510m performs at its best constantly. Fitted with multi dot technology making it possible to carry out deeper markings it becomes your go-to solution for direct part marking. Utilizing high precision zero play ball screws and high rigidity guide rails, the XF510 is designed to be robust and running problem-free in the most demanding of environments.

3 models available (L x W x H)

Cm: 158 x 102 x 275 mm (6.2 x 4 x 10.8 in)

Sm: 231 x 195 x 309 mm (9 x 7.7 x 12.1 in)

Dm: 331 x 195 x 309 mm (13 x 7.7 x 12.1 in)

• I-SENSE

The I-Sense function detects the surface of the workpiece, automatically adjusts the height of the Z-axis and starts marking with no intervention on the part of the operator. Several adjustment modes are available: automatic mode (I-Sense), programmable mode and normal mode, which allows manual adjustment.

• DYNAMIC DOT CONTROL

Obtain a perfect result every time with the XF510m DDC™ (Dynamic Dot Control) feature, a technology which enables automatic adjustment of point density according to the required size and depth of marking. Your markings are of high quality and easy to read, whatever your application. Two setting modes available:

automatic and manual.

• MARK WHAT YOU WANT

Be it 2DCode, Dates, Counters, Variables, Text, Serial numbers, shape, logo, batch number, in all languages. Mark it on metal and some hard plastics the electromagnetic technology makes it easier and more accurate than ever.

• SAME SPOT MARKING

With the ability to accurately mark the same place with up to 10 impacts it is now possible to carry out clearer markings on difficult material. This meets the depth requirements of most industrial sectors! With just the one stylus the XF510m is a versatile, universal solution.

• DATAMATRIX SPECIALIST

Datamatrix code marking requires meeting the standards and respecting the real-world traceability workflow. The electromagnetic technology allows us to obtain a perfect reading of the 2D code in all situations: Grade A Same dot diameter Equal distance between dots. Can be read back from any direction. 0% error. Mark any type of 2D code: Datamatrix, QR code, UID, GS1, Unicode characters safe in the knowledge that our ultra-precise M1L stylus will be providing unparalleled accuracy.

Download Catalogue

Ask About This
XF530m (Electromagnetic)
This is the perfect solution to identify parts that will withstand harsh conditions, direct marking before part processing and for anti-counterfeiting markings.

• DEEP MARKING

With up to 0.5 mm depth, the XF530 dot peen machine is the only deep engraving solution able to reach this level of depth in such a short cycle time. The marking results are clear and resistant to weather conditions, contaminants, rust, and guaranteed long-term readability. Its also the best solution to perform a direct marking before part processing, painting, or surface treatment.

• DEDICATED SOLUTION FOR LARGE CHARACTERS

The XF530 large marking area of 200 X 50 mm (8 x 2 in) is specially adapted to engrave large characters (more than 10mm (0.4 in) height) for easy readability from a long distance or in outdoor locations. This deep dot peen marking machine is the perfect solution for the oil & gas market and building industries.

• ROBUST & DURABLE

This deep dot peen engraving machine in pneumatic or electromagnetic version is made of high quality and high-performance components. Its proven design has been improved for decades to obtain exceptional durability and reliability, especially in the most demanding applications. XF530 is guaranteed to have durable tamper-proof marks on all materials with a reduced cost of ownership.

• ELECTROMAGNETIC VERSION FOR PRECISION

The electromagnetic marking machines are more suitable for applications needing great precision and consistency. It is perfect to create durable tamper-proof marks 2D codes. The electromagnetic version has the highest amplitude, allowing it to absorb a height difference of 7mm, making it the preferred solution for curved parts.

• MOBILE SOLUTION (Optional)

Our range of products is easily transformable into a mobile solution to mark large parts and parts that cannot be dismantled, on fixed stations or scrolling vehicle lines: a pair of large handles for easy positioning. With a standard or customizable foot, the machine is always firmly positioned on the part. 2 rings at the top that can be connected as a balancer making easy operator work, suppress troubles related to heavy handling and to integrate into pipeline marking.

Download Catalogue

Ask About This
XF510r (Scribing)
This online marking system delivers direct part marking on your parts while keeping noise to a minimum. Quiet enough to meet the noise controls in the strictest standards, it is the industrial solution for marking metal sheets.

• SILENT MARKING

Scribing technology makes sense on hollow metal parts (tubes and pipes) or formed plates (chassis and body parts) which will naturally resonate during rotary marking. Scribing, by reducing the number of impacts, will allow a smooth and silent marking with high contrast, making it easier to proofread. Thanks to the Datamatrix kit, we offer you the possibility to switch to a dot peen machine when you need to mark a 2D code.

• HIGH MARKING QUALITY

Designed to combine depth with aesthetic results: speed, strength, and position can be configured for perfect direct part marking consistency and legibility meaning a high possibility to survive at the painting process. This gives the highest quality characters with the existing fonts.

• STRONG & DURABLE

Composed of high rigidity guide rails and high-performance styluses: high amplitude, anti-burrs, and a diamond tip. The power and precision of this DPM machine come from the quality of its construction, ensuring the user high performance, low maintenance, power, and air consumption.

• DATAMATRIX KIT

The XF510r range provides an unmatched marking speed, quality, and reliability both for low and high volume production. With the optional Datamatrix kit, code and characters are perfectly marked in a single operation and in record time.

3 models available (L x w x h)

Cr: 182 x 167 x 199.5 mm (7.2 x 6.5 x 7.9 in)

Sr: 222 x 167 x 199.5 mm (8.7 x 6.6 x 7.9 in)

Dr: 302 x 167 x 199.5 mm (11.9 x 6.6 x 7.9 in)



Download Catalogue

Ask About This
